Specifications
Output Power Cable Specifications M/B 20+4Pin CPU 4+4Pin PCI-Ex 6+2Pin + 6+2Pin SATA ODD/HDD/FDD 550mm 650mm 500mm+150mm 500mm+150mm+150mm+150mm 500mm+150mm+150mm+150mm
Electrical & Physical Characteristics AC Input Range Voltage 100 ~ 240VAC Vout Output Load Rating Combined Frequency 50 ~ 60Hz Imin Imax Ipeak AC Input Current 100VAC 7A +3.3V 0.2A 22A 140W 550W 240VAC 3.5A +5V 0.2A 18A PFC Type Active PFC +12V 0.3A 45A 48A 540W Power Factor Max 99% -12V 0.0A 0.3A 3.6W Inrush Current Limit 115VAC Max 150A +5VSB 0.0A 2.5A 3.5A 12.5W 230VAC Max 200A Ambient Temperature Efficiency Max 92% @ 230VAC, Typical load Operation 0 ~ 40°C DC Output Vout Regulation Range At Full Storage -20 ~ 80°C +3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity +5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95%RH +12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95%RH -12VDC ±10% -10.8 ~ -13.0V Protection Features +5VSB ±5% +4.75 ~ +5.25V Over Voltage Protection(OVP) DC Output Vout Standard Range At Full Under Voltage Protection(UVP) +3.3VDC 50mV Over Current Protection(OCP) +5VDC 50mV Short Circuit Protection(SCP) +12VDC 120mV Over Temperature Protection(OTP) -12VDC 120mV Over Power Protection(OPP) +5VSB 50mV Dimensions MTBF Up to 100,000 hours 180(L) x 150(W) x 86(H) mm
